G2 CSR horn - problem and questions

Postby WiltshireMike » Wed Nov 04, 2020 7:02 pm

I've just started to re-commission my 1966 G2CSR and have sadly managed to cook the actuating coil in the Lucas HF1441 horn. So, two questions:

1/ The Parts Manual lists an HF1849 (domed rear cover) horn for my bike and I'm wondering whether a previous owner has fitted the HF1441 (flat plate tone disc with brass nut) or whether it was on the bike as built. The bike appears to be pretty much standard in most respects, so can anyone with a late G2CSR / 14CSR please let me know which horn theirs has? I'd like to keep it as original as possible, so I need either to source an 1849, or repair the 1441.

2/ To disassemble the horn for repair I need to remove the diaphragm securing nut but this requires a combination of 1" flat hex spanner plus a stout 3-4mm blade tool to retain the armature sleeve as according to an old Lucas instruction guide (courtesy of the web) the nut is torqued to almost 40 ft-lbs. Has anyone done this themselves - any tips??

Many thanks in advance ...

Member
Posts: 602
Joined: Thu Mar 31, 2005 12:00 am
Location: BERKS UK

Re: G2 CSR horn - problem and questions

Postby Andy51 » Thu Nov 05, 2020 5:38 pm

I have tried to repair a Lucas horn in the past without success, and I know they are expensive to have done professionally. Although I am not familiar with your particular model, you can get modern horns that fit inside the Lucas case for around a tenner - they sound a bit cheap and tinny but then once the bike is running the engine noise is louder than the horn anyway! Hope this helps, Andy

Member
Posts: 18
Joined: Mon Nov 02, 2020 10:54 am
Location: Wiltshire UK

Re: G2 CSR horn - problem and questions

Postby WiltshireMike » Thu Nov 05, 2020 10:24 pm

Thanks Andy, I've given up on opening the horn as I'll only end up damaging it. Question 1/ is still open if anyone can help ...?

Member
Posts: 5
Joined: Tue Oct 06, 2020 9:32 am
Location: Berks, UK

Re: G2 CSR horn - problem and questions

Postby KRM » Sat Nov 07, 2020 9:20 am

Hi,
I’ve recently had the same issue. Whilst the parts list states a Lucas HF 1849 I was told that the later models use a Lucas 8H which are significantly cheaper and easier to source And a lot easier to fix. I’ve looked at as many pictures as I can find and can’t find any with a 1849 horn. The domed back cover also seems too big to fit properly.... but there is the problem. Trust the parts listing or pictures and word of mouth.....


My 61 G12 CSR uses a 1441 which I got refurbished together with the laminated bracket ( which is essential) from taffhonrns. Unfortunately he has had a stroke and no longer rebuilds them.

I’m not obsessed with originality but if I’m going to do it I’d like to get it correct as much as possible and the research is part of the project.

If anyone has any pictures or advice please chip in.

Member
Posts: 18
Joined: Mon Nov 02, 2020 10:54 am
Location: Wiltshire UK

Re: G2 CSR horn - problem and questions

Postby WiltshireMike » Mon Nov 09, 2020 8:39 pm

Hi KRM,

As you say, the Parts List shows an 1849.

The 1441 on my G2 CSR was mounted with a single vertical bolt from the LHS side cover screw mount, but looking closer the bike actually has the correct 2x 1/4" hole mount bracket to the rear of that, which will match the 2-hole 1849. I've tracked down what I hope will be a decent working 1849 so will find a new home for the 1441.

Ah, the (new-found) joys of what I anticipated to be a light re-commissioning.

Member
Posts: 7026
Joined: Wed Sep 01, 2004 12:00 am
Location: WEST SUSSEX UK

Re: G2 CSR horn - problem and questions

Postby SPRIDDLER » Mon Nov 09, 2020 8:46 pm

WiltshireMike wrote:Hi KRM,

As you say, the Parts List shows an 1849.

The 1441 on my G2 CSR was mounted with a single vertical bolt from the LHS side cover screw mount, but looking closer the bike actually has the correct 2x 1/4" hole mount bracket to the rear of that, which will match the 2-hole 1849. I've tracked down what I hope will be a decent working 1849 so will find a new home for the 1441.

Ah, the (new-found) joys of what I anticipated to be a light re-commissioning.


That's detailed restoration not light re-commissioning. Horns are available for less than a tenner on eBay. ;)
I poke badgers with spoons.....from 2 metres.

Member
Posts: 18
Joined: Mon Nov 02, 2020 10:54 am
Location: Wiltshire UK

Re: G2 CSR horn - problem and questions

Postby WiltshireMike » Mon Nov 16, 2020 8:06 pm

Thanks Spriddler, I need saving from myself! Anyways, the 1849 arrived yesterday; nice patina, a loud 'toot' and a tenner. Oh, and also a NOS clutch cover too - wasn't a tenner 😒 but it replaced the cracked 'M'-flashed item.

Member
User avatar
Posts: 1441
Joined: Sat Oct 09, 2010 8:17 pm
Location: SWANSEA UK

Re: G2 CSR horn - problem and questions

Postby cbranni » Mon Nov 16, 2020 9:08 pm

I poke badgers with spoons.....from 2 metres.

Tell me Spridds does that spoon that you use to poke badgers with have a two meter handle ............ could you tell me if it's similar to a Norfolk dyke dish then?

Just curious.

Colin
only dead fish go with the flow

Member
Posts: 7026
Joined: Wed Sep 01, 2004 12:00 am
Location: WEST SUSSEX UK

Re: G2 CSR horn - problem and questions

Postby SPRIDDLER » Mon Nov 16, 2020 9:33 pm

cbranni wrote:I poke badgers with spoons.....from 2 metres.

Tell me Spridds does that spoon that you use to poke badgers with have a two meter handle ............ could you tell me if it's similar to a Norfolk dyke dish then?

I'm not familiar with dishy Norfolk dykes Colin, although I see Brighton ones at our annual St. Dykes Day Fair with drag racing on the prom.
Yes, it does have a 2m handle. My great grandfather, Master of the local Badger Poking Hunt used to make them. Mine's one of his traditional two yard spoons which was found to be too long.

(Totally off topic and irrelevant. Apologies. I blame CV19 lockdown fever).
